01 Meet multi model carrier canning

The mat is a non expandable mat with excellent bending performance, which is suitable for a variety of different canning process. The products can be used for most carriers, including diesel engine, gasoline engine, gas engine and other large-diameter, thin-walled even very thin-walled carriers.
02 Good anti-aging performance

PCW mat, alumina content ≥ 72%, good high temperature aging stability, and withstand temperature up to 1300℃, Low thermal conductivity, which can effectively prevent the shell of three-way catalytic converter from overheating.
03 Good corrosion resistance and blowing resistance

Good corrosion resistance, excellent resistance to all chemicals except hydrogen fluoride, phosphoric acid and strong base. Blow erosion resistance loss ≤ 1%, which can withstand stronger airflow impact, ensure product performance, prevent waste gas leakage and product failure, and is applicable to national emission standard VI.
04 High friction coefficient, high safety performance

High friction coefficient and good stability, which can provide long-term stable and reliable physical support for all kinds of carriers, with higher safety performance.
05 Strong design
It can be customized according to customer needs, with good flexibility and plasticity, and can adapt to various canning technologies currently used.

Product structure: composed of alumina fibre and adhesive

Fibre content: 90~97% binder content: 3~10% (Avg:6.5%)

  Customized according to customer requirements

产品型号 Product model	DH100丨1200	DH100丨1600	DH100丨2250
标准面密度 (g/m2)  Nominal	1200±10%	1600±10%	2250±10%
面密度最小值 (g/m2 )  MIN areal density	1080	1440	2025
面密度最大值 (g/m2)  MAX areal density	1320	1760	2475
标准厚度 (mm)  Nominal	8.5±0.9	10.7±1.1	14±1.6
厚度最小值 (mm)  Minimum	7.6	9.6	12.4
厚度最大值 (mm)  Maximum	9.4	11.8	15.6
封装密度 (g/cm3)  GBD	0.35~0.55	0.35~0.55	0.35~0.55
封装间隙 (mm)  Gap	2.2~3.4	2.9~4.6	4.5~7.5



The only high-end production product in the whole industry chain in China

■ AFIBRE mat is widely used in vehicle exhaust emission system to protect and seal honeycomb ceramic carrier. It is applied to TWC (three-way catalytic converter) and GPF (gasoline particulate filter) in gasoline vehicles，and also DOC(diesel oxidation catalyst), DPF (diesel particulate filter) and SCR (selective catalytic reduction) in diesel vehicles.
